XX-20K20A
XIANGXING
20K2000WA
Technical Parameters
| Model | XX-20K20A |
| Usage | Plastic welding |
| Power supply | AC220V or 110V |
| Power | 2000W |
| Frequency | 20KHz |
| Horn journey | 75mm |
| Delay time | 0.00-9.99s |
| Welding time | 0.00-9.99s |
| Cooling time | 0.00-9.99s |
| Net weight | 75KG |
| Machine size | 1080*650*400mm |
| Trade mark | XIANGXING |
| Origin | Shenzhen China |
Packing and Delivery:
| Transport package | Carton/ Wooden case |
| Package size | 1200mm*750mm*500mm |
| Package Gross weigh | 150KG |
| Port | Shenzhen seaport |
| Supply Ability | 150 Set/Sets per Month |
Lead Time: Enjoy the assurance of timely deliveries with our precise lead times that are crafted to match your project schedules, ensuring your processes remain smooth and uninterrupted.
| Quantity (sets) | 1 - 3 | 4 - 5 | 6 - 10 | >10 |
| Lead time (days) | 3 | 5 | 10 | To be negotiated |
Product Description
Working Principle:Experience the marvel of ultrasonic technology as it harnesses ultrasonic vibrations through a specialized transmission welding head to seamlessly join parts. This process exploits the acoustic resistance between the two welding parts, generating localized high temperatures that melt the interface. With the application of specific pressure, both components fuse elegantly, producing a final product that boasts a smooth, flawless, and robust finish worthy of admiration.
Automatic Frequency Generator
Experience the cutting-edge technology of our automatic frequency modulation function, which empowers the ultrasonic generator to autonomously track and adjust to the frequency changes in the welding head. This ensures optimal performance even when faced with challenges such as elevated temperatures, wear, or foreign materials on the welding head's surface.
Ultrasonic Transducer
At the heart of our ultrasonic plastic welding machine is the essential transducer, responsible for generating pressure and vibration. This vital component ensures that two workpieces are seamlessly welded together for a reliable bond.
Start Button and Emergency Button
Our innovative two-green-start-button design requires simultaneous pressing, ensuring unparalleled safety by preventing operation with a single hand. This advanced feature safeguards the operator, minimizing the risk of hand injury during operation.
In the event of any emergency, swiftly press the red emergency button to halt the machine instantly. This crucial feature provides efficient protection for the operator, enhancing overall safety.
Height Adjust Handwheel
Our machine boasts the ability to adjust height effortlessly, accommodating products of varying heights. With an impressive maximum adjustable height of 510mm, versatility and adaptability are guaranteed.
Adjustment Handle
These two precision-engineered handles are designed to fine-tune the machine's tension, ensuring optimal performance and reliability.
Limit Screw and Leveling Screw
The limit screw offers precise height adjustments between the welding jig and the product, ensuring superior welding effects and consistency.
Utilize these four leveling screws to meticulously calibrate the machine's balance, guaranteeing stability and precision during operation.
